Prostore 500 2½ Door Digital Freezer, 470lt (-15/-22 °C) - R290 (COD 691354)
Where to buy
Prostore 5002½ Door Digital Freezer, 470lt (-15/-22 °C) - R290
Prostore Digital 500 liters (R290)

Prostore 500
2½ Door Digital Freezer, 470lt (-15/-22 °C) - R290

COD 691354

2-door prostore Freezer 470lt, -22-15°C, AISI 304, R290

Where to buy

Specifications

  • Supply voltage: 220-240 V/1 ph/50 Hz

    Electrical power max.: 0.41 kW

  • Gross capacity: 470 lt

    Net Volume: 317 lt

    Door hinges: Right Side

    External dimensions, Width: 600 mm

    External dimensions, Depth: 700 mm

    External dimensions, Depth with Doors Open: 1226 mm

    External dimensions, Height: 2040 mm

    Number and type of doors: 2x1/2 Full

    Internal Dimensions, Width: 472 mm

    Internal Dimensions, Depth: 582 mm

    Internal Dimensions, Height: 1474 mm

    Height adjustment: 15/40 mm

    Type of external material: 304 AISI

    Type of internal material: 304 AISI

    Number of positions & pitch: 44; 22 mm

  • Energy Class (EU Reg. 2015/1094): D

    Yearly and daily energy consumption (EU Reg. 2015/1094): 2100kWh/year - 6kWh/24h

    Climate class (EU Reg. 2015/1094): Heavy Duty (5)

    Energy Efficiency Index-EEI (EU Reg. 2015/1094): 69.21

    Noise level: 55 dBA

    Refrigerant type: R290

    GWP Index: 3

    Refrigeration power: 569 W

    Refrigerant weight: 145 g

  • Type of model (EU Reg. 2015/1094): vertical frozen

  • Number and type of grids (included): 5 - 520x442

  • Control type: Digital

    Compressor power: 3/4 hp

    Refrigeration power at evaporation temperature: -30 °C

    Operating temperature min.: -22 °C

    Operating temperature max.: -15 °C

    Operating mode: Ventilated

    Cooling unit: Built-In

    Defrost type: Electric

  • ISO Standards: ISO 9001; ISO 14001; ISO 45001; ISO 50001

Product Features

IPX5 frontal water protection.
Large digital white-digit display with cabinet temperature display and setting and turbo frost cycle (to rapidly cool warm loads).
Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory).
Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated. Up to two months of event are kept in memory.
Large storage area suitable to contain 520x442 mm grids or shelves to improve net capacity.
Optimized airflow within the chamber guarantees uniformity of temperature on all grids.
Hidden evaporator thus guaranteeing higher storage capacity and less corrosion problems.
Greater storage space: internal structure with numerous charging positions available to host grids, ensuring higher net capacity.
Adjustable temperature range from -15°C to -22°C.
Model requires only 1 phase 230V/50Hz supply and can be plugged straight into an existing power socket.
Tropicalized unit.
Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Complies with main international certification bodies and is CE marked.
Prearranged for remote alarm.
Self closing and on site reversible left/right doors.
Low noise level.
This appliance is intended for use in ambient temperatures up to 40°C.
Stainless steel AISI 304 external panels (galvanized external back).
Inner cell with rounded corners, bottom pressed in only one piece.
Lockable door.
Stainless steel runners and supports easily disassembled.
Internal components removable without the use of tools to facilitate cleaning operations.
Pressed stainless steel door handle without joints gathering dust and dirt.
Easy access to the main components for maintenance.
Developed and produced in ISO 9001 and ISO 14001 certified factory.
Automatic heated door frame.

Included Accessories

Quantity
Code
Description
Quantity: 4
Code: 880335
Pair of runners for 470 and 720lt prostore cabinets
Quantity: 4
Code: 880342
Rilsan-coated grid 520x442mm for Prostore 470l
