Prostore 500 1 Glass Door Digital Refrigerator, 470lt (0/+10 °C) left hinged - R290 (COD 691347)
Where to buy
Prostore Digital 500 liters (R290)

Prostore 500
1 Glass Door Digital Refrigerator, 470lt (0/+10 °C) left hinged - R290

COD 691347

1-glass door prostore Refrigerator 470lt, 0/+10°C, AISI 304, R290, left-hinged

Specifications

  • Supply voltage: 220-240 V/1 ph/50 Hz

    Electrical power max.: 0.21 kW

  • Gross capacity: 470 lt

    Net Volume: 317 lt

    Door hinges: Left Side

    External dimensions, Width: 600 mm

    External dimensions, Depth: 700 mm

    External dimensions, Depth with Doors Open: 1226 mm

    External dimensions, Height: 2040 mm

    Number and type of doors: 1 Glass

    Internal Dimensions, Width: 472 mm

    Internal Dimensions, Depth: 582 mm

    Internal Dimensions, Height: 1474 mm

    Height adjustment: 15/40 mm

    Type of external material: 304 AISI

    Type of internal material: 304 AISI

    Number of positions & pitch: 44; 22 mm

  • Energy Class (EU Reg. 2015/1094): D

    Yearly and daily energy consumption (EU Reg. 2015/1094): 762kWh/year - 2kWh/24h

    Climate class (EU Reg. 2015/1094): Heavy Duty (5)

    Energy Efficiency Index-EEI (EU Reg. 2015/1094): 67.45

    Noise level: 57.5 dBA

    Refrigerant type: R290

    GWP Index: 3

    Refrigeration power: 406 W

    Refrigerant weight: 85 g

  • Type of model (EU Reg. 2015/1094): vertical chilled

  • Number and type of grids (included): 5 - 520x442

  • Control type: Digital

    Compressor power: 1/4 hp

    Refrigeration power at evaporation temperature: -10 °C

    Operating temperature min.: 0 °C

    Operating temperature max.: 10 °C

    Operating mode: Ventilated

    Cooling unit: Built-In

    Defrost type: By Air

  • ISO Standards: ISO 9001; ISO 14001; ISO 45001; ISO 50001

Product Features

Large storage area suitable to contain 520x442 mm grids or shelves to improve net capacity.
IPX5 frontal water protection.
Adjustable temperature range from 0°C to +10°C.
Model requires only 1 phase 230V/50Hz supply and can be plugged straight into an existing power socket.
Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated. Up to two months of event are kept in memory.
Complies with main international certification bodies and is CE marked.
Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory).
This appliance is intended for use in ambient temperatures up to 40°C.
Internal all-round door LED lighting for best visibility.
Greater storage space: internal structure with numerous charging positions available to host grids, ensuring higher net capacity.
Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Optimized airflow within the chamber guarantees uniformity of temperature on all grids.
Hidden evaporator thus guaranteeing higher storage capacity and less corrosion problems.
Low noise level.
Tropicalized unit.
Stainless steel AISI 304 external panels (galvanized external back).
Developed and produced in ISO 9001 and ISO 14001 certified factory.
Pressed stainless steel door handle without joints gathering dust and dirt.
Internal components removable without the use of tools to facilitate cleaning operations.
Easy access to the main components for maintenance.
Inner cell with rounded corners, bottom pressed in only one piece.
Stainless steel runners and supports easily disassembled.
Lockable door.

Included Accessories

Quantity
Code
Description
Quantity: 5
Code: 880335
Pair of runners for 470 and 720lt prostore cabinets
Quantity: 5
Code: 880342
Rilsan-coated grid 520x442mm for Prostore 470l
