Prostore 500 1 Door Digital Freezer, 470lt (-15/-22°C) R290 (Marine) 50Hz (COD 691388)
Where to buy
Prostore Digital 500 liters (R290)

Prostore 500
1 Door Digital Freezer, 470lt (-15/-22°C) R290 (Marine) 50Hz

COD 691388

1-door prostore Freezer 470lt, -22-15°C, AISI 304 - R290 (Marine) 50Hz

Specifications

  • Supply voltage: 220-230 V/1 ph/50 Hz

    Electrical power max.: 0.49 kW

  • Gross capacity: 470 lt

    Net Volume: 317 lt

    Door hinges: Right Side

    External dimensions, Width: 600 mm

    External dimensions, Depth: 700 mm

    External dimensions, Depth with Doors Open: 1226 mm

    External dimensions, Height: 2040 mm

    Number and type of doors: 1 Full

    Internal Dimensions, Width: 472 mm

    Internal Dimensions, Depth: 582 mm

    Internal Dimensions, Height: 1474 mm

    Height adjustment: 15/40 mm

    Type of external material: 304 AISI

    Type of internal material: 304 AISI

    Number of positions & pitch: 44; 22 mm

  • Number and type of grids (included): 4 - 520x442

  • Control type: Digital

    Compressor power: 3/4 hp

    Refrigeration power at evaporation temperature: -30 °C

    Operating temperature min.: -22 °C

    Operating temperature max.: -15 °C

    Operating mode: Ventilated

    Cooling unit: Built-In

    Defrost type: Electric

  • Refrigerant type: R290

    Refrigeration power: 568 W

    Refrigerant weight: 125 g

  • ISO Standards: ISO 9001; ISO 14001; ISO 45001; ISO 50001

Product Features

Adjustable temperature range from -15°C to -22°C.
Performance guaranteed at ambient temperatures of +40°C (Climatic class 5).
Large digital white-digit display with cabinet temperature display and setting and turbo frost cycle (to rapidly cool warm loads).
Optimized airflow within the chamber guarantees uniformity of temperature on all grids.
Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory).
Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated.
Greater storage space: internal structure with numerous charging positions available to host grids, ensuring higher net capacity.
Hidden evaporator thus guaranteeing higher storage capacity and less corrosion problems.
Large storage area suitable to contain 520x442 mm grids or shelves to improve net capacity.
AISI 304 runners with grids stopper for Marine installations.
Self closing and on site reversible left/right doors.
Model requires only 1 phase 230V/50Hz supply and can be plugged straight into an existing power socket.
Tropicalized unit.
Low noise level.
Complies with main international certification bodies and is CE marked.
Stainless steel AISI 304 external panels (galvanized external back).
Pressed stainless steel door handle without joints gathering dust and dirt.
Inner cell with rounded corners, bottom pressed in only one piece.
Easy access to the main components for maintenance.
Internal components removable without the use of tools to facilitate cleaning operations.
Lockable door.
Mounted on Marine feet.
Kit of 4 feet H=67mm available as optional in case of ceiling up to 2100mm.
Developed and produced in ISO 9001 and ISO 14001 certified factory.
Automatic heated door frame.

Included Accessories

Quantity
Code
Description
Quantity: 4
Code: 880327
Kit pair of runners (marine)
Quantity: 4
Code: 880342
Rilsan-coated grid 520x442mm for Prostore 470l
