Pastry and Bakery Line 4 Door Refrigerated Counter, -2°/+7°C, 600X400 grid (COD 728971)
Where to buy
Pastry and Bakery Line Refrigerated and Freezer Counters (R290)

Pastry and Bakery Line
4 Door Refrigerated Counter, -2°/+7°C, 600X400 grid

COD 728971

4-door Refrigerated Counter, 600x400 mm grids, -2+7°C, AISI 304

Specifications

  • Supply voltage: 230 V/1N ph/50 Hz

    Electrical power max.: 0.247 kW

  • Gross capacity: 727 lt

    Net Volume: 480 lt

    N° of doors: 4

    Door hinges: 1 Left+3 Right

    External dimensions, Width: 2562 mm

    External dimensions, Depth: 800 mm

    External dimensions, Depth with Doors Open: 1280 mm

    External dimensions, Height: 950 mm

    Type of external material: Stainless Steel AISI 304 Scotch Brite

    Type of internal material: 304 AISI

    Internal side panels material: 304 AISI

  • Energy Class (EU Reg. 2015/1094): A

    Yearly and daily energy consumption (EU Reg. 2015/1094): 582kWh/year - 2kWh/24h

    Climate class (EU Reg. 2015/1094): Heavy Duty (5)

    Energy Efficiency Index-EEI (EU Reg. 2015/1094): 24

    Refrigerant type: R290

    GWP Index: 3

  • Type of model (EU Reg. 2015/1094): counter chilled

  • Control type:

    Refrigeration power at evaporation temperature: -10 °C

    Operating temperature min.: -2 °C

    Operating temperature max.: 7 °C

Product Features

Suitable for use in ambient temperature of up to 40°C (climatic class 5).
Adjustable temperature range from -2°C to +7°c.
Electronic control panel and digital display.
Frontal access for easy maintenance.
Internal runners removable without any tools for faster cleaning operations.
Adjustable feet from 140mm to 240mm.
The position of the evaporator and the design of the internal ventilation facilitate the uniformity of the temperature.
Stainless steel AISI 304 internal and external panels including back.
Rounded internal corners for ease of cleaning.
Self closing doors.

Included Accessories

Quantity
Code
Description
Quantity: 12
Code: 880673
Pair of runners 600x400 mm for Pastry Counter
