Digital Undercounter ecostore HP Premium Freezer Counter - 440lt, 3-Door, Cooling Unit Right (COD 710102)

Compare Where to buy

ecostore HP Premium Freezer Counters - 3 comp. with top

Digital Undercounter
ecostore HP Premium Freezer Counter - 440lt, 3-Door, Cooling Unit Right

COD 710102

3-door Freezer Counter 440lt, -22-15°C, AISI 304, with right cooling Unit

Compare

Where to buy

Specifications

Electric

Supply voltage: 220-240 V/1 ph/50 Hz

Electrical power max.: 0.49 kW

Defrost Power: 0.57 kW

Plug type: CE-SCHUKO
Sustainability

Current consumption: 3.3 Amps

Energy Class (EU Reg. 2015/1094): D

Yearly and daily energy consumption (EU Reg. 2015/1094): 2242kWh/year - 6kWh/24h

Climate class (EU Reg. 2015/1094): Heavy Duty (5)

Energy Efficiency Index-EEI (EU Reg. 2015/1094): 53,50

Refrigerant type: R290

GWP Index: 3

Refrigeration power: 569 W

Refrigerant weight: 145 g
Key Information

Gross capacity: 440 lt

Net Volume: 310 lt

Door hinges: 1 Left+2 Right

External dimensions, Width: 1799 mm

External dimensions, Depth: 700 mm

External dimensions, Height: 900 mm

Internal Dimensions, Width: 1252 mm

Internal Dimensions, Depth: 560 mm

Internal Dimensions, Height: 550 mm

Net weight: 120 kg

Shipping volume: 1.5 m³

Depth with doors open: 1110 mm

Height adjustment: -5/50 mm
Refrigeration Data

Control type: Digital

Compressor power: 3/4 hp

Refrigeration power at evaporation temperature: -30 °C

Min/Max internal humidity:

Operating temperature min.: -15 °C

Operating temperature max.: -22 °C

Operating mode: Ventilated

Insulation: 90 mm (Cyclopentane)
ISO Certificates

ISO Standards: ISO 9001; ISO 14001; ISO 45001; ISO 50001

Documents

Product Features

Certified safety CE requirements.

Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory).

Combination of doors and drawers to suit any configuration need, with the possibility to change the configuration on site.

Adjustable temperature range from -15°C to -22°C.

Preservation performances and temperature uniformity within the cell guaranteed at 5-HEAVY DUTY (40°C) working conditions according to EN16825:2016 test protocol.

Large digital white-digit display with humidity selection button (3 preset level), internal temperature display and setting, manual activation of defrost cycle and turbo frost cycle (to rapidly cool warm loads).

Equipped with Optiflow forced air circulation system for rapid cooling and temperature distribution within the cell.

Electrolux Professional Fridge Control APP make the life easier for our customers: - Monitor safety of preservation process thanks to HACCP data & alarms for precise control- Save time and easy data management having the possibility to send the HACCP information in excel format directly to e-mail address- Quick operations: set the cabinet temperature/turbocooling and set date/hour

0mm clearance installation space: tower configuration cooling unit guarantee performance with frontal ventilation only; this unique solution allows installation against the wall or side by side with other appliances, even on the cooling unit side to maximize the use of kitchen space.

Fully removable cooling unit to facilitate maintenance.

Frontal and easy access to all components in the cooling unit.

Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated. Up to two months of event are kept in memory.

Anti-tilt runners accept GN 1/1 containers.

Tropicalized unit.

Self closing stainless steel doors (< 90°).

Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.

Hot gas automatic evaporation of defrost water.

If needed, working top can be removed for easier handling during installation (in case of narrow doors).

3 compartments with 3 doors.

Internal structure with 15 charging positions (3 cm pitch) available to host GN 1/1 grids, ensuring higher net capacity and a greater storage space.

Ease of cleaning and high hygiene standards thanks to the rounded internal corners, the easily removable runners, grids and air conveyors.

Interior base with rounded corners, pressed from a single sheet.

Anti-drip profile on stainless steel worktop edge.

Internal and external doors, front and side panels and removable worktop in AISI 304 Stainless steel.

External bottom panel in stainless steel.

External back panel in galvanized steel.

Built-in refrigeration unit.

Developed and produced in ISO 9001 and ISO 14001 certified factory.

Fault code display.

Worktop in AISI 304 Stainless steel with a 50 mm profile.

Mounted on Stainless steel legs to give 150 mm clearance for ease of cleaning the floor.

Included Accessories


Quantity

Code

Description

Quantity: 3

Code: 881109

Kit 1/1 grey rilsan grid and 2 side runners for refrigerated counters
